SmartD: How the Clean Power VFD Solves Long Cable Run Issues

SmartD: The Long Cable Run Dilemma – Where Should You Install the VFD?

The long cable run dilemma – where should you install the VFD? Sophia, a dedicated electrical engineer in a large industrial complex, has been tasked with installing a drive system where the motor is located hundreds of meters away from the control room. Like many engineers before her, she considers the usual question. Should I place the drive in the electrical room or near the motor itself? Placing the Drive in the Electrical Room: On the plus side, it keeps delicate electronics in a clean, temperature-controlled environment, making servicing easier and extending the drive’s lifespan. However, this setup demands long cable runs to the remote motor, which can mean voltage spikes, special filters, and potentially higher costs due to larger cable cross-sections and EMI concerns.

Beckhoff: EL3443 | EtherCAT Terminal, 3-Channel Analog Input

The EL3443 EtherCAT Terminal enables the measurement of all relevant electrical data of the supply network and carries out simple pre-evaluation. The voltage is measured via direct connection of L1, L2, L3 and N. The current of the three phases L1, L2 and L3 is fed via simple current transformers. All measured currents and voltages are available as root-mean-square values. In the EL3443 terminal, the effective power and energy consumption for each phase are calculated. The RMS values of voltage U and current I as well as the active power P, apparent power S, reactive power Q, frequency f, phase shift angle cos φ and harmonic are available. The EL3443 offers extended functionality for mains analysis and energy management. In addition, the EL3443 comes with the option of transmitting the time of the last voltage zero crossing to the controller via XFC technology. This can be used, for example, to carry out switching operations to suit the application. The EL3443 can be ordered for other current ranges, such as 5 A, 100 mA or 333 mV. An overview of the different versions can be found under Related products.

Jacmar: Yaskawa A1000 2/2Hp 200-240V 3-Phase Drive

Jacmar: Yaskawa A1000 2/2Hp 200-240V 3-Phase AC Drive

The A1000 is a full featured drive, providing outstanding quality, performance, flexibility, and environmental friendliness through 1000HP. Enjoy network communications, feedback, and expandable I/O to control anything from simple fans and pumps to complex machines. For new installations or retrofits, the A1000 provides a single robust solution, regardless of your application.

Phoenix Contact Expands Color RJ45 Patch Cables for CAT6A Applications

Phoenix Contact is extending its product portfolio with color patch cables from the RJ45 Building series, which have been specially developed for applications in control cabinets. The new cables are available in eight colors: white, orange, yellow, red, violet, green, blue, and black. High-speed data transmission at up to 10 Gbps (CAT6A) makes the RJ45 patch cables ideal for future-proof office, building, and protected industrial applications, such as in control cabinets. Worldwide approvals, including CE, cUL, WEEE, and EAC, enable international use. The reliable locking clip protection enables reliable connection and disconnection, while 360° shielding offers ideal EMC properties. The patch cables are available in lengths from 0.3 m to 50 m.

Hammond: Water-Tight with Integrated Hinge, Diecast Enclosure – R133-134 Series

The R133-134 Series diecast enclosures are designed to protect electrical and electronic components effectively. They come in a variety of sizes and design options including IP66 / IP67 / IP68, IP69K with included PUR gasket versions for harsh environments. NEMA ratings 1, 4, 4X, 12 & 13 available as well as being RoHS and REACH compliant.

SICK: SIG300 – IO-Link Master

The SIG300 Sensor Integration Gateway is a high-performance IO-Link Master with eight ports (class A/B) that consolidates the data from the connected devices and forwards them to the higher-level system. The gateway provides up to 16 A, which is sufficient power for energy-intensive sensors and actuators. With variants for PROFINET, EtherNet/IP and EtherCAT as well as a REST API version, the SIG300 can be integrated into almost any system environment. Thanks to the programmable logic editor, simpler tasks can be executed autonomously and remotely. This shortens the response times for automated processes. Furthermore, the integrated web server allows fast, intuitive parameterization. Select your variant.

New KSC XA Tactile Switches from Littelfuse Deliver Soft Sound Tactile Feedback for Enhanced User Experience

KSC XA Series Soft Sound Tactile Switches are an effective solution for applications requiring quiet, reliable tactile feedback. Designed for surface-mount technology (SMT) applications, the KSC XA switches deliver an innovative soft sound for a quieter user experience, an extended cage for potting compatibility, and a high actuation force option for precise, deliberate operation. These characteristics make the KSC XA switches ideal for industries where noise reduction, durability, and reliability are critical, such as automotive, medical, industrial, and premium consumer electronics. The KSC XA series offers engineers an innovative combination of soft tactile feedback, compact size, and high environmental resistance. With an IP67 rating for protection against dust and moisture and a robust hard actuator design, the KSC XA switches ensure long-lasting performance in harsh environments. Their extended cage design supports encapsulation with potting material, providing additional protection against corrosion and environmental stress.

Electromate: eX715MG – Web & Outdoor HMI

The eX715MG Web HMI combines high-performance sunlight-readable display with state-of-the-art connectivity features and top browsing performance in a great design maintaining as a design commitment the fact that the product is likely to be used in environments where the safety of operators is at risk. The eX715MG is the ideal choice for all demanding IIoT edge applications in outdoor and extreme environments such as marine and process industries where powerful and performing HTML5 web browser is needed. The glass projected capacitive touchscreen and the brilliant 15-inch widescreen display with a resolution of 1920×1080 are bonded to guarantee the highest optical performance and resistance in such environments.

Rittal: Baying Systems TS 8 Enclosures

Due to its symmetrical profile in terms of width and depth, the TS 8 baying system, made from carbon steel, saves considerable space and facilitates easy internal installation. It also allows a baying arrangement on all sides. In addition, the integrated, automatic potential equalization of all enclosure panels and the triple machining of the surface ensures maximum safety. Supplies included are the enclosure frame, door(s) right-hand door catch on single-door enclosures may be swapped to the left, roof plate, rear panel, 4 eyebolts, lock with 3 mm double-bit, base plates, mounting panel, 2 TS punched rails, 18 x 38 mm, 2 support strips fitted in the enclosure depth

Rockwell Automation Revolutionizes Motor Controls with Smarter & Safer M100 Electronic Motor Starter 

The M100 Electronic Motor Starter enables industrial organizations to simplify panel wiring and reduce component and engineering complexities with advanced functional safety solutions and more refined motor starting capabilities.  Rockwell’s traditional motor starters lay a robust foundation for customizable motor control solutions including starting, stopping and protecting motors. Building on this legacy, the new M100 Electronic Motor Starter seamlessly integrates into intelligent motor control setups, boosting productivity and minimizing downtime. It serves as a cost-effective, space-efficient option, boasting an extensive range of features designed to improve performance across various applications. Notably, the M100 incorporates point-on-wave (POW) switching technology. The new M100 Electronic Motor Starter offers zero stacking with no derating up to 55C, providing flexibility in installation without compromising performance. Removable terminal blocks, available in both screw and push-in variants, add convenience and adaptability. The M100 also supports direct-on-line (DOL), reversing, and safety capabilities in the same form factor, showcasing its flexibility in various operational scenarios.

Mouser: Carlo Gavazzi – CON M8 & M12 IP67 Cord Sets

Carlo Gavazzi CON M8 and M12 IP67 Cord sets feature 3 or 4 wires for the M8 version and 3, 4, or 5 wires for the M12 version. These cord sets are available with a straight or right-angle plug with either a female or male orientation. Additionally, these cord sets come in single- or double-ended designs and offer standard lengths of 2m or 5m. Specifications include an IP67 protection degree, PVC cable jacket, and a wide operating temperature range of -25°C to +80°C. Carlo Gavazzi CON M8 and M12 IP67 Cord sets are constructed with high-quality materials and designed to provide easy installation and maintenance.

Wieland: HMI ECO Touch Panels

The industrial grade HMI ECO touch panels have become essential for all machines and systems as they are purposefully used for visualization, operation and diagnosis purposes. Critical machine status information is immediately visible to the operator to reach the highest level of overall equipment effectiveness. HMI panels allow a smooth operation of a machine and in case of a machine failure enable the initiation of adequate countermeasures since all important machine data are available. Together with the samos PRO safety controller, the HMI forms an ideal solution for your complete automation. With the “MyLogo” campaign Wieland offers you a customized design with your own logo and individual color scheme.

Techspan: Fusetek Medium Voltage “E” & “R” Rated Fuses

MV fuses are current and energy limiting fuses intended for the backup protection of medium voltage motor control. They are non-venting. MVR fuses have integral striker/indicators and have standardized dimensions compatible with today’s
5.5kV motor control gear. They are fully interchangeable with other manufacturers’ fuses of the same type and rating. They feature a ‘field toughened’ element design which makes them less susceptible to mechanical damage during shipping and installation while also providing superior cycling characteristics.

Weidmuller: U-Control M3000/M4000 – Modular Controls for Industrial Automation & IoT Applications

In the course of automation, more and more physical devices are being integrated into networks. This is driving the trend towards convergence of IT and OT systems. The new modular u-control M3000 and M4000 control systems point the way to the future. With u-control M3000, automation solutions can be perfectly integrated into the IoT. The powerful controller also works as an edge device for providing local information in the network and can be expanded by connecting function modules – ideal for automation and IIoT applications. u-control M4000 also offers two CPU cores, two Ethernet interfaces and more RAM, NVRAM, and flash memory for complex edge computing in automation.

Proax: The Complete Guide to DIN Rail Types & Applications

DIN rail is a standardized mounting solution that has become the backbone of modern electrical control panels and equipment racks. Originally developed by the German Institute for Standardization (Deutsches Institut für Normung, or DIN), these metal rails have evolved into an essential component across various industries. As an authorized distributor of Phoenix Contact DIN rails, Proax is committed to providing you with comprehensive knowledge about these versatile mounting systems. DIN rail is a metal rail of a standardized type widely used for mounting control equipment in electrical panels and equipment racks. The term “DIN” refers to the German national standards organization that first standardized these rails. Today, DIN rails follow the European standard EN 60715 (formerly DIN EN 50022), which has been adopted worldwide.

ABB: Miniature Circuit Breakers (MCBs)

Miniature Circuit Breakers (MCBs) ensure electrical safety in homes, offices and other buildings as well as for industrial applications by protecting electrical installations against overloads and short-circuits. Once a fault is detected, the MCB automatically switches off the electrical circuit to prevent damage to wires and to avoid the risk of fire. MCBs are equipped with two tripping mechanisms: the delayed thermal tripping mechanism for overload protection and the magnetic tripping mechanism for short circuit protection. For 100 years, ABB has continued to innovate MCBs and expand their product line to meet the demands of various applications and markets. ABB’s products are compliant with global product standards such as IEC, UL and CSA. This established and certified portfolio is designed to provide maximum safety for buildings, assets and infrastructure.
