Hammond Manufacturing: HYW Series Hygienic Type 4X Stainless Steel Wallmount Enclosure
![](https://www.panelbuildersystemsintegrator.ca/wp-content/uploads/2023/11/PB-74-Hammond-HYWSeriesHygienicEnclosure-1200-1024x536.jpg)
November 6, 2023
Introducing the HYW series of hygienic type 4X stainless steel wallmount enclosures from Hammond Manufacturing, designed to enclose electrical and/or electronic equipment and protect against harsh, hygienic environments for wallmount applications. A sloped top prevents water from resting on top as well as providing potential for controls mounting, while an internal hinge design and door-edge mounted silicone gasket allow for easy cleaning in hose-down environments. A wide range of sizes and practical accessories make this product line a complete package.
HYW Series Standards
- UL 508A Type 3R, 4, 4X and 12
- cUL Type 3R, 4, 4X and 12
- NSF – ANSI 169
- Not all accessories shown maintain NSF standard. Some are internal and NSF is not applicable. Refer to each accessory individually or call factory for specifics.
- Complies with
- NEMA 3R, 4, 4X, 12 and 13
- IEC 60529, IP 66, IP69, IP69K
HYW Series Construction
- Formed, smooth 304 stainless steel.
- Top sloped 25°
- Continuously welded seams ground smooth.
- Door stiffeners are provided where required for increased strength and rigidity.
- Hygienic door latches (316 stainless steel quarter turns) require use of tool for opening.
- Interior hinges provide 105 degree opening, are easily removed for reverse door swing or on-site modifications.
- Silicone gasket (hygienic blue) mounts around entire door edge allowing for efficient cleaning in hygienic environments.
- Gasket can be easily removed and re-installed for cleaning or replacement.
- Internal alignment guide provided to limit door sag.
- Collar studs provided for mounting inner panel.
- Includes hardware kit with panel mounting nuts.
- No pre-drilled wall mounting holes allow for flexible mounting alternatives – weld-in-place, stand-offs
- Bonding stud provided on door and grounding stud installed in enclosure.
Finish
- Cover and enclosure are natural stainless steel with a smooth #4 dairy finish.
