Mouser: RECOM Power RACPRO1 DIN-Rail Power Supplies
January 6, 2025
RECOM Power RACPRO1 DIN-Rail Power Supplies deliver 240W, 480W, or 960W for demanding industrial applications. These power supplies provide an outstanding lifetime of 80,000+ hours, high mains input surge immunity of up to 6kVAC, and high return voltage immunity of >35V at the output. The series also supports an extended temperature range of -40°C to +70°C. The slim, ergonomic design features 25° tool-less and maintenance-free, push-in connectors for both inputs and outputs.
The RACPRO1 family from RECOM includes four-channel electronic fuse (e-Fuse) load switches that share many of the same features as the power supplies, including a universal, three-phase AC input voltage range of 3x320VAC to 3x576VAC and a universal DC input voltage range of 430VDC to 850VDC to support renewable energy and microgrid applications.
RACPRO1 Features
- Slim design (43mm, 52mm, and 80mm) with 25° push-in connectors
- Fast tool-less mounting and demounting
- 430VDC to 815VDC/850VDC input range (10s)
- High efficiency of up to 96.9%
- Full power from -40°C to +60°C temperature range and 150% boost power for 5s
- 120% thermal power bonus at +45°C
- High lifetime expectancy of 80,000hrs at +40°C
- DC-OK signal
- Reduced no-load power consumption ranging from 0.8W to 3.3W
- Lineup includes 4-channel electronic fuse (e-Fuse) load switches with independent overcurrent limit control and real-time output current indication
- 3-year warranty
Applications
- Industrial automation
- Factory and building automation
- Process automation
- Power generation
- Energy distribution
- Test and measurement
- Infrastructure
- Datacom and telecom
